$10,159.00

Free shipping

DJI Matrice 4 Thermal

The DJI Matrice 4 Thermal (4T) supports infrared High-Res Mode, with image resolutions up to 1280 × 1024. It also offers Ultra-High Resolution, revealing small temperature details for various operations. Each device undergoes temperature accuracy calibration and utilizes an onboard temperature sensor to provide real-time temperature measurements.

The DJI Matrice 4 Series, a new compact and intelligent multi-sensor flagship drone series for enterprise industries. The series includes Matrice 4T and Matrice 4E, each equipped with advanced features such as smart detection and measurement with laser range finder. Flight operations are now safer and more reliable with significantly enhanced sensing capabilities. The accessories for the Matrice 4 series have also been significantly upgraded. The Matrice 4T is suitable for a wide range of industries, including electricity, emergency response, public safety, and forestry conservation. The Matrice 4E is designed for geospatial applications such as surveying and mapping, construction, and mining. A new era in intelligent aerial operations begins now.

DJI Matrice 4 thermal drone

Laser Range Finder

Measurement Range: 1800 m (1 Hz); Oblique Incidence Range (1:5 Oblique Distance): 600 m (1 Hz) Blind Zone: 1 m; Range Accuracy (m): ± (0.2 + 0.0015 × D)

The built-in model can detect vehicles, vessels, and subjects during search and rescue operations or routine flights. It also supports switching to other models, enabling the expansion of application scenarios. Additionally, it supports high-res grid photos and features powerful tracking capabilities.

Infrared Thermal Camera

Thermal Imager

  • Uncooled vanadium oxide (VOx)

Pixel Pitch

  • 12 μm

Frame Rate

  • 30 Hz
Lens
  • DFOV: 45°±0.3°
    Equivalent focal length: 53 mm
    Aperture: f/1.0
    Focus: 5 m to ∞

Sensitivity

  • DJI Matrice 4T: ≤50mk@F1.0

Temperature Measurement Method

  • Spot Meter, Area Measurement

Temperature Measurement Range

  • High Gain Mode: -20℃ to 150℃ (-4°F to 302°F) ()
    Low Gain Mode: 0℃ to 550℃ (32°F to 1022°F)

Palette

  • White Hot/Black Hot/Tint/Iron Red/Hot Iron/Arctic/Medical/Fulgurite/Rainbow 1/Rainbow 2

Photo Format

  • JPEG (8bit)、 R-JPEG (16bit)

Video Resolution

  • 1280 × 1024@30fps (Super Resolution enabled, Night Mode not activated)
    Other conditions: 640 × 512@30fps

Video Bitrate

  • 6.5Mbps (H.264 640 × 512@30fps)
    5Mbps (H.265 640 × 512@30fps)
    12Mbps (H.264 1280 × 1024@30fps)
    8Mbps (H.265 1280 × 1024@30fps)

Matrice 4T Video Format

  • MP4

Still Photography Modes

  • Single: 1280 × 1024/640 × 512
    Interval: 1280 × 1024/640 × 512
    JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s

Photo Resolution

  • Infrared: 1280 × 1024 (Super Resolution on)
    640 × 512 (Super Resolution off)

Digital Zoom

  • 28x

Infrared Wavelength

  • 8um to 14um

Infrared Temperature Measurement Accuracy

  • High Gain: ±2℃ or ±2%, whichever is greater
    Low Gain: ±5℃ or ±3%, whichever is greater
